TE Connectivity Unveil New M12 Cable Assemblies for Rail

TE Connectivity (TE), a world leader in connectivity and sensors, has extended its modular twisted pair cable assembly offering with new M12 cable assemblies. Conforming to EN45545 HL3 with fire and smoke characteristics, TE’s M12 cable assemblies are suitable for public transportation and other heavy industrial applications.

TE%20Connectivity

Their rugged design enables them to withstand the vibrations experienced in trains and other demanding environments.

Egbert Stellinga, product manager at TE Connectivity, said:

“Our M12 cable assemblies meet the demand for increasing digitization in applications such as rail data communication systems”

“They deliver the best data speed possible, up to 10 Gb/s, and are highly robust to enable the best passenger experience combined with safe and reliable transportation.”

Rugged Cable Assemblies for Rail, Transportation and Heavy Industrial Applications.

TE’s series of standard M12-to-M12 cable assemblies uses compact, straight and right-angled connectors allowing the cable to be used in confined areas. The full metal shell in combination with Secure cable shield termination makes the system EN50155 compliant. Together with fire and smoke compliance, the cable can withstand severe shocks and vibrations according to EN 61373 Cat1 Class B due to its rugged design and machined contacts.

The unique crimped cable strain relief contributes to the high data speed and also eliminates conductor breakage that could lead to system failure. In addition, the crimping system creates a tamper-proof installation, preventing accidental unlocking of the strain relief. High speed category 5e or 7 cable ensures they meet future requirements, allowing the them to be used in later network upgrades.

M12 cable assemblies are IP67 sealed and 100 percent tested in TE’s factory to eliminate the possibility of false wiring. They are available in lengths from 1.0 to 20 m in 0.5 m increments, plus special lengths can be handled on request. They come pre-assembled, reducing installation time and enabling quick implementation of data networks.

About TE Connectivity

TE Connectivity Ltd. is a $13 billion global technology and manufacturing leader creating a safer, sustainable, productive, and connected future. For more than 75 years, our connectivity and sensor solutions, proven in the harshest environments, have enabled advancements in transportation, industrial applications, medical technology, energy, data communications, and the home. With 78,000 employees, including more than 7,000 engineers, working alongside customers in nearly 150 countries, TE ensures that EVERY CONNECTION COUNTS. Learn more at www.te.com and on LinkedIn, Facebook, WeChat and Twitter.
